RADAR ARCHES
RADAR ARCHES
Radar Arches Boats up to 27'


Our custom RadarArch.com division specializes in building the most complete, state of the art, highest quality radar arches for individual boat owners. From recreational fishing boats to large pleasure yachts and worldwide sailing vessels, we offer the finest designed arches available.


Buying An Arch From Us Is Easy!


Appointment

When you are ready for your arch, contact us and we will make an appointment to meet you at your boat.


Engineering

We first establish the best place to bolt the arch that is accessible for internal wiring and backing plates and generate blueprints to work from.


Aesthetics

We take the lines of your boat and mirror them in the design of the arch. From the side, we use the windshield, cowling line or front of the flybridge. From the aft looking forward, we use the cabin or windows, and we crown the top of the arch to pick up the lines of your rooftop, canvas and decks. When done correctly, your arch should be a showpiece from any angle.


Meeting Your Needs

All of our arches come with one set of antenna plates and one radome plate. You can add any additional plates or mounts you need and all will come pre-drilled for easy installation when you provide us with your radar model and any templates needed. Each arch also comes with one horizontal crossmembers on each side. Taller arches may need another set of crossmembers for aesthetics and structural strength. Although the primary function of a radar arch is for mounting electronics and antennas, they also function as an excellent hand hold and plalform for bimini supports, deck lights, or speakers.


Work Order

After the blueprints are complete, we fill out a work order that details exactly what we will be building, including optional features, wiring specifications, cost and completion date. We require a half down deposit with the balance due upon completion, approximately two weeks later.


Our Goal

Our goal is to provide the highest quality product on the market through fine design, superior workmanship, and top of the line service.


Standard Features

+ Type #316-L mirror polished #8 stainless steel tubing, 1 1/4", 1 1/2", or 2" O.D.
+ Internal frame (full size arches)
+ Two 3 1/2" x 8" antenna or light plates
+ One 11 x 13 radome mounting plate
+ Pre-drilled radome and antenna plates
+ Machined holes for internal wiring
+ One horizontal crossbar on each side
+ Guaranteed to fit your specifications


Optional Features

+ Additional antenna/light plates
+ Additional horizontal crossmembers
+ U.S.C.G. approved 360 degree swiveling anchor light
+ Hinge assembly
+ Rod holder crossbar
+ Welded-on wakeboard tow hook
+ Deck light mounts
+ Welded-on deluxe stainless rod holders


Radar Arches Boats 28' and Larger


Our custom RadarArch.com division specializes in building the most complete, state of the art, highest quality radar arches for individual boat owners. From recreational fishing boats to large pleasure yachts and worldwide sailing vessels, we offer the finest designed arches available.


Buying An Arch From Us Is Easy!


Appointment

When you are ready for your arch, contact us and we will make an appointment to meet you at your boat.


Engineering

We first establish the best place to bolt the arch that is accessible for internal wiring and backing plates and generate blueprints to work from.


Aesthetics

We take the lines of your boat and mirror them in the design of the arch. From the side, we use the windshield, cowling line or front of the flybridge. From the aft looking forward, we use the cabin or windows, and we crown the top of the arch to pick up the lines of your rooftop, canvas and decks. When done correctly, your arch should be a showpiece from any angle.


Meeting Your Needs

All of our arches come with one set of antenna plates and one radome plate. You can add any additional plates or mounts you need and all will come pre-drilled for easy installation when you provide us with your radar model and any templates needed. Each arch also comes with one horizontal crossmembers on each side. Taller arches may need another set of crossmembers for aesthetics and structural strength. Although the primary function of a radar arch is for mounting electronics and antennas, they also function as an excellent hand hold and plalform for bimini supports, deck lights, or speakers.


Work Order

After the blueprints are complete, we fill out a work order that details exactly what we will be building, including optional features, wiring specifications, cost and completion date. We require a half down deposit with the balance due upon completion, approximately two weeks later.


Our Goal

Our goal is to provide the highest quality product on the market through fine design, superior workmanship, and top of the line service.


Standard Features

+ Type #316-L mirror polished #8 stainless steel tubing, 1 1/2", 2" or 2 1/2" O.D.
+ Internal frame
+ Two 3 1/2"x9" antenna or light plates
+ One 11 x 13 radome mounting plate
+ Pre-drilled radome and antenna plates
+ Machined holes for internal wiring
+ One horizontal crossbar on each side
+ Guaranteed to fit your specifications


Optional Features

+ Additional antenna/light plates
+ Additional horizontal crossmembers
+ U.S.C.G. approved 360 degree light standard
+ Hinge assembly
+ KVH mounting plates with wire cover plates
+ Solar panel and wind generator mounts
+ Deck light mounts
+ Welded-on deluxe stainless rod holders
